Standard Features

• 400°C/120 min (F400)
• Continuous operation up to 120°C media
• Casing made of zinc-magnesium coated steel (ZM)
• Backward curved impeller made from pre-galvanised steel 120°C (size 355, 450) respectively from steel and galvanised
• Motor outside the air stream
• Single speed IE2 motors rsp. two speed motors
• PTC serial built-in motor
• Certified according EN 12101-3 by BSI, UK
• Dual purpose (normal ventilation plus smoke and heat extract)
• ErP compliance 2018
• Installation possible in all positions, flange connection 30 mm
• Installation outside building or inside building, outside fire zone in well ventilated rooms
• Applications: malls, garages, warehouses, kitchen exhaust
